Auto control modern production Poultry feed production line for
feed plant
Our Poultry feed production line is developed based on our 20 year
manufactuer experience. It is auto control by control cabin,
high performance and easy to set up. For different capacity need,
we have different design.
Ring Mould Animal Feed Pellet Machine are the main machine of
making granular fodder, it can be used to make various roughage
andrefined fodder in livestock farm and feed mill, and also used
for checmical industry, fertilizer industry and sugar industry.
Pellet machine animal feed making machine is suitable for use in
small farms, with good quality, high efficiency, save engry. pellet making machine alfafa pelletizer Pellet making machine animal feed is convenient operation, reliable
sealing, high production rate, low power consumption, low labor
strength.
Specification:
| Model No. | Main Power
(kw) | Feeder Power
(kw) | Adjusor power
(kw) | Capacity
(Ton/hr) |
| SZLH250 | 22 | 1.5 | 2.2 | 0.5-1.5 |
| SZLH304 | 30/37 | 1.5 | 2.2 | 1-3 |
| SZLH320 | 37 | 1.5 | 2.2 | 2-4 |
| SZLH350 | 55 | 1.5 | 3 | 3-6 |
| SZLH400 | 75 | 2.2 | 3 | 7-10 |
| SZLH420 | 90 | 2.2 | 3 | 10-15 |
The main pallet machine in our production line is circle palleting
mould. Can press and pallet continuously in high speed.
It is used for turning the raw material of corn stalk, straw, bean
stem, sweet potato alcohole, and other biomass material into the
feed for caw, pig, sheep, rabbit, chicken, duck, fish.
Granules Size suitable for different animals:
1. For pig, the pellet diameter is usually ø3.5-6.5mm.
2. For cattle, the pellet diameter is usually ø4.5-8mm.
3. For chicken, pellet diameter is usually ø3.2mm.
4. For fish, pellet diameter is usuallyø2.0, ø2.5, ø3.0mm.
5. For shrimps, pellet diameter is usually ø1.0-ø3.5mm.
Pellet length is customized.
Advantages:
1. Increase the animal feed digestibility for 12%, reduse the
material waste 10%
2. All Stainless steel feeding inlet and adjustor, spiral feeding
is even, particle surface is smooth.
3. Diameter from 1.5mm to 12mm, can be customized
Application:
The pallet it produce is 3.0-3.5mm, this prodcution line can also
produce powder feed.
Loading and shipping:
1. Small machine packed in the wooden box.
2. Production line or large quantity packed in the container.
3. Also could packing according to customers' requests.
4. We accept EXW,FOB,CFR,CIF etc...
5. Accept inspection before shipping or when loading in containers.
Service we provided
1. Free consultation service before, during, and after sales;
2. Free Project planning and design services upon clients' special
demands;
3. Debugging and inspecting of equipment until everything is
functional before leaving the factory;
4. Overseas installation and training of equipment maintenance and
operating personally;
5. Provide basic production techniques and formulas;
6. 1 year complete warranty for Machine.
