Feed Plant Poultry feed production line equipment for 1-20 Ton per hr

Pellet mill has the world-class technology adopted to produce many kinds of animal feed. The bearing, oil seal, O-rings of the drive part are all import. The design, quality and façade of the machine are in the international advanced level. The main drive parts use high-precision gear revolve, with this the production improved 15%-20%. The transmission gear uses high-precision gear grinding, reduced the vibration and noise. The outside painting uses automatic painting process. Paint is bright and firm. It adopts the quick-release clamp under clamping mechanism, and can be equipped with the worm gear and worm ring mould lifting device, enhances the working efficiency of the ring die, reduce the labor intensity. Modulation system adopts stainless steel extension modulation tube, very health, the modulation time and service life is longer. There are many steam adding inlets. Raw material is heated more fully. Conditioner effect is better. Configurable oil circulating cooling system, in order to enhance the cooling and lubrication effect of the main drive system of bearing. The device can work smoothly for a long time.

Models:

Features of the Rign die pellet machine

1. Ring die pellet model can improve the production capacity.

2. Adopts high accuracy gearbox for high efficiency.

3. Stainless steel conditioner to ensure the high quality of pellet feed.

4. Siemens motor, SKF bearing

5. High output, low noise, compact structure, convenient operation and maintenance

Raw material of the feed production line:

1. Cereals:soybean, maize,corn, grain,sorghum,corn flour , wheat flour ,crop stalks (corn stalk, sorghum stalk, cotton, rape stalk, peanut seedling, sunflower stalk), chaff, grasses, shrubs

2. Coarse fiber: wheat bran, corn stalk, soybean meal,grass meal,rice husk, grass, groundnut shell, cottonseed hull.

3. Additives: molasses, vegetable oil, Amino acid, bone meal, vitamin.

The line consists 6 sections

1. Crushing Section

When the thickness of the raw material is >5 mm, the raw materials must be used for size reduction before the feedstock is sent to the hammer mill (crusher) to reach a diameter of less than 3 mm.

2. Mixing Section

Two open doors structure, discharge rapidly, no leakage, no residue. Multiform liquid adding system and can be matched with compressed air jetting system Suitable for mixing premix, poultry feed, aquatic feed, additives and chemical and medicine industries, etc

3. Pelletizing Section

Acting as the heart part of the whole processing line, ring die pellet mill through adjusting the rotational speed of screw feeder axis to obtain the suitable flow of material, through the enforced feeder, enter the pressing room to pelletize finally.

4. Cooling Section

After the pelletizing process, the temperature of the feed pellet is about 60-80 degrees Celsius, with a moisture content of about 15%. A Cooler must then be used to reduce the moisture content of the wood pellets to about 3-4%, thereby making the feed pellets easier to store.

5. Classifying screen

It is applicable for screening and classifying of mash or pellet feed. It is also can be used for cleaning of raw materials and classifyingof semi finished products after second grinding.

by large and medium feed mills.

6. Packing Section

After cooling and screening, the feed pellet must be protected from moisture and other environmental conditions. For this there is the packing process, which is effectively handled by our Semi-Auto Packing Machine.

Application:

Powder feed

Pallet feed

Our service

1. Free consultation service before, during, and after sales.

2. Free Project planning and design services upon clients' special demands.

3. Debugging and inspecting of equipment until everything is functional before leaving the factory.

4. Overseas installation and training of equipment maintenance and operating personally.

5. Provide basic production techniques and formulas.

6. 1 year complete warranty for Machine.

Zhengzhou shenghong heavy industry technology co.,ltd. (short for “Shenghong Technology”)

is recognized globally as an expert in process design and equipment manufacturer on feed industry, including feed pellet production line with 5000 to 100000 tons per year and powder feed production line with 5000 to 200000 tons per year.

Our company has professional and technical personnel and production management elites in many industries, and has rich on-site operation experience. Our company is mainly engaged in the construction and transformation of various scales of livestock and poultry feed, aquatic products and special aquatic feed, premixed feed, additives, fermented feed, pasture feed and other projects. We can also provide customers with various types of single-machine equipment and accessories for high-quality feed production lines such as crushing, mixing, granulating, cooling, crushing, grading, and quantitative packaging.

Since its establishment, the company has continuously introduced new products on the basis of digesting and absorbing the advanced achievements of domestic and foreign products, which are widely sold in dozens of countries at home and abroad, and have won unanimous recognition from customers.

After several years of intensive cultivation in the feed industry, the company now has a number of domestic and international certificates, including CE certificate, ISO9001 certification, and we also have our own patent certificate, BV certificate and so on.
