Concentrated Powder Feed Production Line For Making Poultry Animal
Chicken Feed
Product description o animal powder feed production line
The concentrated material production line has a first grease
spraying equipment, a first mixing equipment, a first crushing
equipment and a first batching equipment. The first grease spraying
equipment is used to add fat to the feed intermediate; the first
mixing equipment is used to fully mix the fat and the feed
intermediate so that the components are uniformly mixed; the first
crushing equipment is used to mix the first mixing equipment The
evenly mixed feed intermediate is pulverized and refined to achieve
the particle size required by the process; the first batching
equipment is used to mix the feed intermediate after the first
pulverizing device is crushed and refined with other components
according to the set ratio The preset components have been obtained
to ensure the quality of the final feed product. In this
concentrated feed production line, the grease produced by the first
grease spraying equipment is mixed by the first mixing equipment
and then specially pulverized and refined by the second pulverizing
equipment to reach the set particle size, and the pulverized feed
intermediate is passed through The first batching equipment can get
the preset composition and high-quality concentrated material.
Parameter of animal powder feed production line
Item
Model | Volume m3 | Mixing Amount per Batch(kg) | Mixing Time Per Batch(s) | Mixing Homogeneity (cv≤%)
| Power(kw) |
| SSHJ 2 | 2 | 1000 | 30-120 | 3-5 | 15/18.5 |
| SSHJ 4 | 4 | 2000 | 30-120 | 3-5 | 30/37 |
| SSHJ 6 | 6 | 3000 | 30-120 | 3-5 | 37/45 |
| SSHJ 8 | 8 | 4000 | 30-120 | 3-5 | 45/55 |
Advantage of animal powder feed production line
1.The unit integrates the main raw and auxiliary raw material
transportation and automatic weighing, pulverization, liquid
automatic weighing, mixing, dust removal and other processes;
modular design, assembly-type intensive production;
2.No complicated assembly after unloading, wiring can be used;
Covering an area of 2.5 meters 4 meters, the height is only 2.8
meters, the general house can be installed and used; Simple
operation, integrated automatic control system, analog dynamic
display touch control, one-button automatic continuous production,
convenient and simple mode;
3.Front and rear configurable storage system, granulation system,
weighing automatic packaging system, combined complete set of
full-price powder, pellet feed unit.
Features of animal powder feed production line
1. It uses the SKF bearings, NAK oil seal to make sure the
high-efficiency, stable performance and low noisy of the whole
machine. And it uses the Siemens or yutong brand of motor.
2. The feed powder production line has reasonable technology, high
capacity and low energy consumption.
3. The feed powder production line is compact, occupies less floor
space and has low requirement on the mill tower, and needs low
investment in civil works.
4. To solve farmers' shortage of protein feed.
5. The operation is simple and convenient.
Process of animal powder feed production line
The unit integrates the main raw and auxiliary raw material
transportation andautomatic weighing, pulverization, liquid
automatic weighing, mixing, dust removal and other processes;
modular design, assembly-type intensive production;
No complicated assembly after unloading, wiring can be used;
Covering an area of 2.5 meters 4 meters, the height is only 2.8
meters,the general house can be installed and used.
